ndn::security::v2::ValidationPolicyCommandInterest Class Reference

Validation policy for stop-and-wait command Interests. More...

#include <validation-policy-command-interest.hpp>

Inheritance diagram for ndn::security::v2::ValidationPolicyCommandInterest:
Collaboration diagram for ndn::security::v2::ValidationPolicyCommandInterest:

Classes

class  Options


Public Member Functions

 ValidationPolicyCommandInterest (unique_ptr< ValidationPolicy > inner, const Options &options={})
 constructor More...

- Public Member Functions inherited from ndn::security::v2::ValidationPolicy
virtual ~ValidationPolicy ()=default

void setInnerPolicy (unique_ptr< ValidationPolicy > innerPolicy)
 Set inner policy. More...

bool hasInnerPolicy () const
 Check if inner policy is set. More...

ValidationPolicygetInnerPolicy ()
 Return the inner policy. More...

void setValidator (Validator &validator)
 Set validator to which the policy is associated. More...

virtual void checkPolicy (const Certificate &certificate, const shared_ptr< ValidationState > &state, const ValidationContinuation &continueValidation)
 Check certificate against the policy. More...


Protected Member Functions

void checkPolicy (const Data &data, const shared_ptr< ValidationState > &state, const ValidationContinuation &continueValidation) override
 Check data against the policy. More...

void checkPolicy (const Interest &interest, const shared_ptr< ValidationState > &state, const ValidationContinuation &continueValidation) override
 Check interest against the policy. More...


Additional Inherited Members

- Public Types inherited from ndn::security::v2::ValidationPolicy
using ValidationContinuation = std::function< void(const shared_ptr< CertificateRequest > &certRequest, const shared_ptr< ValidationState > &state)>

- Public Attributes inherited from ndn::security::v2::ValidationPolicy
NDN_CXX_PUBLIC_WITH_TESTS_ELSE_PROTECTED __pad0__: Validator* m_validator = nullptr

unique_ptr< ValidationPolicym_innerPolicy


Detailed Description

Validation policy for stop-and-wait command Interests.

See also
https://redmine.named-data.net/projects/ndn-cxx/wiki/CommandInterest

This policy checks the timestamp field of a stop-and-wait command Interest. Signed Interest validation and Data validation requests are delegated to an inner policy.

Definition at line 42 of file validation-policy-command-interest.hpp.

Constructor & Destructor Documentation

◆ ValidationPolicyCommandInterest()

ndn::security::v2::ValidationPolicyCommandInterest::ValidationPolicyCommandInterest ( unique_ptr< ValidationPolicy inner,
const Options options = {}
)
explicit

constructor

Parameters
innera Validator for signed Interest signature validation and Data validation; this must not be nullptr
optionsstop-and-wait command Interest validation options
Exceptions
std::invalid_argumentinner policy is nullptr

Definition at line 28 of file validation-policy-command-interest.cpp.

References ndn::security::v2::ValidationPolicyCommandInterest::Options::gracePeriod, nonstd::optional_lite::std11::move(), NDN_THROW, and ndn::security::v2::ValidationPolicy::setInnerPolicy().

Member Function Documentation

◆ checkPolicy() [1/2]

void ndn::security::v2::ValidationPolicyCommandInterest::checkPolicy ( const Data data,
const shared_ptr< ValidationState > &  state,
const ValidationContinuation continueValidation
)
overrideprotectedvirtual

Check data against the policy.

Depending on implementation of the policy, this check can be done synchronously or asynchronously.

Semantics of checkPolicy has changed from v1::Validator

  • If packet violates policy, the policy should call state->fail with appropriate error code and error description.
  • If packet conforms to the policy and no further certificate retrievals are necessary, the policy should call continueValidation(nullptr, state)
  • If packet conforms to the policy and a certificate needs to be fetched, the policy should call continueValidation(<appropriate-cert-request-instance>, state)

Implements ndn::security::v2::ValidationPolicy.

Definition at line 43 of file validation-policy-command-interest.cpp.

References ndn::security::v2::ValidationPolicy::checkPolicy(), and ndn::security::v2::ValidationPolicy::getInnerPolicy().

◆ checkPolicy() [2/2]

void ndn::security::v2::ValidationPolicyCommandInterest::checkPolicy ( const Interest interest,
const shared_ptr< ValidationState > &  state,
const ValidationContinuation continueValidation
)
overrideprotectedvirtual

Check interest against the policy.

Depending on implementation of the policy, this check can be done synchronously or asynchronously.

Semantics of checkPolicy has changed from v1::Validator

  • If packet violates policy, the policy should call state->fail with appropriate error code and error description.
  • If packet conforms to the policy and no further certificate retrievals are necessary, the policy should call continueValidation(nullptr, state)
  • If packet conforms to the policy and a certificate needs to be fetched, the policy should call continueValidation(<appropriate-cert-request-instance>, state)

Implements ndn::security::v2::ValidationPolicy.

Definition at line 50 of file validation-policy-command-interest.cpp.

References ndn::Name::at(), ndn::security::v2::ValidationPolicy::checkPolicy(), ndn::time::fromUnixTimestamp(), ndn::security::v2::ValidationPolicy::getInnerPolicy(), ndn::security::v2::getKeyLocatorName(), ndn::Interest::getName(), ndn::Interest::getSignatureInfo(), ndn::security::v2::ValidationPolicyCommandInterest::Options::gracePeriod, ndn::security::v2::ValidationPolicyCommandInterest::Options::maxRecords, ndn::command_interest::MIN_SIZE, ns3::ndn::Name, ndn::time::system_clock::now(), ndn::time::steady_clock::now(), ndn::security::v2::ValidationError::POLICY_ERROR, ndn::command_interest::POS_TIMESTAMP, ndn::security::v2::ValidationPolicyCommandInterest::Options::recordLifetime, ndn::Name::size(), ndn::Name::toUri(), and ndn::security::V03.


The documentation for this class was generated from the following files:
