nfd::face::EthernetFactory Class Reference

protocol factory for Ethernet More...

#include <ethernet-factory.hpp>

Inheritance diagram for nfd::face::EthernetFactory:
Collaboration diagram for nfd::face::EthernetFactory:

Public Member Functions

 EthernetFactory (const CtorParams &params)

void processConfig (OptionalConfigSection configSection, FaceSystem::ConfigContext &context) override
 process face_system.ether config section More...

void createFace (const CreateFaceRequest &req, const FaceCreatedCallback &onCreated, const FaceCreationFailedCallback &onFailure) override
 Try to create a unicast face using the supplied parameters. More...

shared_ptr< EthernetChannelcreateChannel (const shared_ptr< const ndn::net::NetworkInterface > &localEndpoint, time::nanoseconds idleTimeout)
 Create Ethernet-based channel on the specified network interface. More...

std::vector< shared_ptr< const Channel > > getChannels () const override

shared_ptr< FacecreateMulticastFace (const ndn::net::NetworkInterface &localEndpoint, const ethernet::Address &group)
 Create a face to communicate on the given Ethernet multicast group. More...

- Public Member Functions inherited from nfd::face::ProtocolFactory
virtual ~ProtocolFactory ()=default

const std::set< std::string > & getProvidedSchemes ()
 Get FaceUri schemes accepted by this ProtocolFactory. More...


Static Public Member Functions

static const std::string & getId ()

- Static Public Member Functions inherited from nfd::face::ProtocolFactory
template<typename PF >
static void registerType (const std::string &id=PF::getId())
 Register a protocol factory type. More...

static unique_ptr< ProtocolFactorycreate (const std::string &id, const CtorParams &params)
 Create a protocol factory instance. More...

static std::set< std::string > listRegistered ()
 Get registered protocol factory ids. More...

static const std::string & getId ()
 Get id for this ProtocolFactory. More...


Additional Inherited Members

- Public Types inherited from nfd::face::ProtocolFactory
using CtorParams = ProtocolFactoryCtorParams

- Protected Member Functions inherited from nfd::face::ProtocolFactory
 ProtocolFactory (const CtorParams &params)

- Static Protected Member Functions inherited from nfd::face::ProtocolFactory
template<typename ChannelMap >
static std::vector< shared_ptr< const Channel > > getChannelsFromMap (const ChannelMap &channelMap)

- Protected Attributes inherited from nfd::face::ProtocolFactory
std::set< std::string > providedSchemes
 FaceUri schemes provided by this ProtocolFactory. More...

FaceCreatedCallback addFace
 callback when a new face is created More...

shared_ptr< ndn::net::NetworkMonitornetmon
 NetworkMonitor for listing available network interfaces and monitoring their changes. More...


Detailed Description

protocol factory for Ethernet

Definition at line 37 of file ethernet-factory.hpp.

Constructor & Destructor Documentation

◆ EthernetFactory()

nfd::face::EthernetFactory::EthernetFactory ( const CtorParams params)
explicit

Definition at line 46 of file ethernet-factory.cpp.

References nfd::face::ProtocolFactory::netmon.

Member Function Documentation

◆ getId()

const std::string & nfd::face::EthernetFactory::getId ( )
static

Definition at line 40 of file ethernet-factory.cpp.

◆ processConfig()

void nfd::face::EthernetFactory::processConfig ( OptionalConfigSection  configSection,
FaceSystem::ConfigContext context
)
overridevirtual

◆ createFace()

void nfd::face::EthernetFactory::createFace ( const CreateFaceRequest req,
const FaceCreatedCallback onCreated,
const FaceCreationFailedCallback onFailure
)
overridevirtual

Try to create a unicast face using the supplied parameters.

Parameters
reqrequest object containing the face creation parameters
onCreatedcallback if face creation succeeds or face already exists; the settings of an existing face are not updated if they differ from the request
onFailurecallback if face creation fails

Implements nfd::face::ProtocolFactory.

Definition at line 169 of file ethernet-factory.cpp.

References ndn::nfd::FACE_PERSISTENCY_ON_DEMAND, ndn::ethernet::Address::fromString(), ndn::FaceUri::getHost(), ndn::FaceUri::isCanonical(), ndn::ethernet::Address::isMulticast(), nfd::face::ProtocolFactory::CreateFaceRequest::localUri, NFD_LOG_TRACE, nfd::face::ProtocolFactory::CreateFaceRequest::params, nfd::face::FaceParams::persistency, nfd::face::ProtocolFactory::CreateFaceRequest::remoteUri, and nfd::face::FaceParams::wantLocalFields.

◆ createChannel()

shared_ptr< EthernetChannel > nfd::face::EthernetFactory::createChannel ( const shared_ptr< const ndn::net::NetworkInterface > &  localEndpoint,
time::nanoseconds  idleTimeout
)

Create Ethernet-based channel on the specified network interface.

If this method is called twice with the same endpoint, only one channel will be created. The second call will just return the existing channel.

Returns
always a valid pointer to a EthernetChannel object, an exception is thrown if it cannot be created.
Exceptions
PcapHelper::Errorchannel creation failed

Definition at line 216 of file ethernet-factory.cpp.

References ndn::net::NetworkInterface::getName().

◆ getChannels()

std::vector< shared_ptr< const Channel > > nfd::face::EthernetFactory::getChannels ( ) const
overridevirtual

◆ createMulticastFace()

shared_ptr< Face > nfd::face::EthernetFactory::createMulticastFace ( const ndn::net::NetworkInterface localEndpoint,
const ethernet::Address group
)

Create a face to communicate on the given Ethernet multicast group.

If this method is called twice with the same arguments, only one face will be created. The second call will just return the existing face.

Parameters
localEndpointlocal network interface
groupmulticast group address
Exceptions
EthernetTransport::Errortransport creation fails

Definition at line 236 of file ethernet-factory.cpp.

References nfd::face::GenericLinkService::Options::allowFragmentation, nfd::face::GenericLinkService::Options::allowReassembly, nfd::face::connectFaceClosedSignal(), ndn::net::NetworkInterface::getName(), and ndn::ethernet::Address::isMulticast().


The documentation for this class was generated from the following files:
